MEJ-FMC410 Slurry Electromagnetic Flow Meter

MEJ-FMC410 Slurry Electromagnetic flow meter

Product Information

MEJ-FMC410 Slurry Electromagnetic Flow Meter

Accuracy: Measurement value±0.5%(Flow velocity 0.5m/s~5m/s)
Direct measured variables ：Flow velocity
Calculated measured variables ：Volume flow , mass flow
Velocity of flow：Typically Velocity of flow：0.5m/s~5m/s
Note：If there are differences in the selection of individual specifications, the label shall prevail, and high-voltage can be customized

MEJ-FMC410 Slurry Electromagnetic flow meter is a flow measurement instrument developed based on Faraday’s law of electromagnetic induction, specifically designed for monitoring the flow of non-magnetic conductive liquids with certain conductivity such as mud and slurry.

Specifications

Product	Electromagnetic flowmeter
Model	MEJ-FMC410
Diameter nominal	DN10~DN1000
Nominal pressure	DN15 – DN250, PN ≤1.6MPa
Nominal pressure	DN300 – DN1000, PN ≤1.0MPa
Accuracy	Measurement value ±0.5%(Flow velocity 0.5m/s~5m/s)
Repetitiveness	0.16%
Liner material	CR,UR,PTFE(F4),FEP(F46),and PTFE(PTA)
Electrode material	316L Stainless Steel, Hastelloy C, Hastelloy B, Ti, Ta, Pt
Medium temperature	Polyurethane: -10…+60℃ ;PTFE/FEP: -10…+120℃;Chloroprene: -10…+70℃；PFA: -10…+120℃
Power supply	AC：85V~264V，50Hz~60Hz; DC：18V~28V
Communications	RS485,MODBUS-RTU
Ingress protection	IP65

MEJ-FMC410

Slurry Electromagnetic
Flow Meter

Can’t Decide? Talk to an Expert?
Have questions or would you like to speak
with an Instrument expert?

FAQs

1. Do you have a minimum order quantity?

Most products have no MOQ limit. For some special products, we will have requirements. For the products you need, you can contact us for confirmation.

2. Are Mejor products customizable to specific requirements?

Yes, Mejor products can be customized to specific requirements, including signal outputs, electrical connections, mounting options, and physical enclosures and so on. We capable to develop instruments tailored to your specific requirements of your special applications.

3. Can Mejor provide technical support and assistance during the installation and operation of its products?

Yes, Mejor provides technical support and assistance during the installation and operation of its products. We understand that customers may require guidance or assistance at various stages of the product lifecycle. And our technical support team is available to answer customer inquiries, provide instructions u0026amp; troubleshooting assistance, and address any technical issues that may arise. Customers can reach out us through emails, phones, or online chat. For after-sales issues, we will response within 1 hour and offer you satisfactory solutions.
